800W LED BSW Framing Profile Cutting Moving Head Light
QL-V800
Quantity:
Technical Specifications
●Input Voltage: 100‑240VAC, 50/60Hz
●Rated Power: 950W
● Light Source: 800W LED
● Rated Life: 20,000 hours
● Beam Angle: 3°‑48°
● Color Rendering Index (CRI): ＞70
● Enhanced CRI Filter: CRI can be boosted to over 90
● Movement: XY 16-bit resolution; Pan (X-axis): 540°, Tilt (Y-axis): 270°, auto position error correction for X/Y axes; equipped with professional pan/tilt precision locking structure
● Strobe Effect: 0‑25Hz adjustable
● Dimming: 0‑100% linear dimming adjustment
● Color Wheel: 1 color wheel (9 colors + open white)
● CTO: Linear color temperature adjustment, 2700K‑6200K
● CMY: Linear CMY color mixing system
●Fixed Gobo Wheel: 1 fixed gobo wheel (12 gobos + open white)
● Rotating Gobo: 7 rotating gobos, each glass gobo supports independent bi-directional rotation (custom gobo plates available)
● Dynamic Effect Wheel: 1 dynamic effect wheel, featuring exquisite water ripple and flame effects, rotatable and replaceable dynamic effects
● Prism & Mirror Effect: 4-facet bi-directional rotating prism + 4-row mirror effect
● Focus: DMX linear focus adjustment
● Frost: Independent frost softening effect
● Shutter Cutting System: 4 shutter blades for fast and smooth cutting; the direction and angle of each blade can be independently controlled
● Single blade supports full blackout; the entire shutter module can rotate ±60°
● Mechanical Iris: 10‑100% continuously adjustable
● Control Modes: DMX512, Art-Net, Auto-run, Sound-activated, Master-Slave, RDM function supported
● Channel Mode: 39CH / 41CH
● IP Rating: IP20
● Housing Material: Fire-retardant and high-temperature resistant nylon engineering plastic
● Power Connection: powerCON input & output
● Signal Connection: 3-pin & 5-pin DMX input & output
●Net Weight: 28kg
● Operating Temperature: -20℃ ~ 40℃
