800W LED BSW Beam Spot Wash CMY CTO Moving Head Light
QL-BSW800
Quantity:
Technical Specifications
●Input Voltage: 100‑240VAC, 50/60Hz
● Rated Power: 950W
● Light Source: 800W LED
● Rated Life: 20,000 hours
● Beam Angle: 3°‑48°
● Color Rendering Index (CRI): ＞70
● Enhanced CRI Filter: CRI can be boosted to over 90
●Movement: XY 16-bit resolution; Pan (X-axis): 540°, Tilt (Y-axis): 270°, automatic X/Y axis position deviation correction; equipped with professional pan/tilt precision locking structure
● Strobe Effect: 0‑25Hz adjustable
● Dimming: 0‑100% linear dimming adjustment
● Color Wheel: 1 color wheel (9 colors + open white)
●CTO: Linear color temperature adjustment, 2700K‑6200K
●CMY: Linear CMY color mixing system
● Fixed Gobo Wheel: 1 fixed gobo wheel (12 gobos + open white)
● Rotating Gobo: 6 rotating gobos, each glass gobo supports independent bi-directional rotation (custom gobo plates available)
● Dynamic Effect Wheel: 1 dynamic effect wheel, featuring exquisite water ripple and flame effects, rotatable and replaceable dynamic effects
● Prism & Mirror Effect: 4-facet bi-directional rotating prism + 4-row mirror effect
●Focus: DMX linear focus adjustment
●Frost: Independent frost softening effect
●Control Modes: DMX512, Auto-run, Sound-activated, Master-Slave, RDM function supported
● Channel Mode: 22CH / 26CH
● IP Rating: IP20
●Housing Material: Fire-retardant and high-temperature resistant nylon engineering plastic
●Power Connection: powerCON input & output
● Signal Connection: 3-pin & 5-pin DMX input & output
●Net Weight: 28kg
●Operating Temperature: -20℃ ~ 40℃
